ZLINE 30 Inch Wall Mount Range Hood Ducted Stainless Steel (687-30)

The ZLINE 687-30 is a 30-inch wall mount range hood designed for efficient ventilation and modern kitchen performance. Constructed from durable 430-grade stainless steel, this ducted range hood delivers reliable airflow and long-lasting use.

This model features a high-performance 4-speed motor with a maximum airflow of up to 700 CFM, effectively removing smoke, grease, and odors from your cooking area. Built-in LED lighting provides clear visibility over the cooktop, while dishwasher-safe stainless steel baffle filters ensure easy maintenance.

The included telescoping chimney pieces allow installation for standard ceiling heights between 8 and 9 feet. Optional extension kits are available for shorter or taller ceiling configurations.

Key Features:

• 30-inch wall mount range hood

• 430-grade stainless steel construction

• Ducted ventilation system (non-recirculating)

• 4-speed fan control with up to 700 CFM airflow

• Dishwasher-safe stainless steel baffle filters

• Integrated LED lighting

• Telescoping chimney for 8 ft to 9 ft ceilings

• Maximum noise level: approximately 56 dB

• Suitable for indoor and outdoor use

Installation & Compatibility

• Ceiling height compatibility:

  • Less than 8 ft: requires Short Kit (SK-687)

  • 8 ft to 9 ft: standard installation

  • 9 ft to 10 ft: requires Extension Kit (1PCEXT-687)

  • 10 ft to 12 ft: requires Extension Kit (2PCEXT-687)

• Compatible crown moldings: CM1-687, CM2-687, CM3-687, CM4-687, CM5-687

Additional Information

• Ductless/recirculating option: Not supported

• Certified for outdoor use: Yes

• Available sizes: 30", 36", 42", 48"
